Phaesun Hybrid Charge Controller All Round 400_24
Product number:
1-02-003040
Shipped in 10-14 Werktage
€267.75*
€225.00**
Product number:
1-02-003040
VAT-exempt delivery possible*
VAT-exempt order for Germany according to § 12 para. 3 UstG
§ Section 12 (3) UstG only applies if you are a private individual and the product is installed in Germany. To benefit from the 0 percent rate, please confirm at the checkout that you are eligible for the zero tax rate according to § 12 para. 3 UstG. Subsequently, the tax rate will automatically be set to zero for eligible items.
The high-end hybrid charge-controller All Round 400-24 from Phaesun was espcially designed for 48V DC offgrid wind/solar hybrid systems.
Thanks to a many control functions the All Round series is very well-suited for wind/solar applications, street lighting or surveillance systems. Technical data:
Reliability: Intellegent, module based design, simple mechanics, various functions. Thanks to high-quality components and a strict production process the regulator is able to last very long even under bad circumstances. Steplessly PWM regulated:
Voltage and current limitating charging mode: when the battery's max. voltage is reached the controller switches to voltage limitating mode. If the voltage, produced by the wind turbine, exceeds the max. voltage the regulator slows down the turbine. Each DC output with various control modes
Thanks to a many control functions the All Round series is very well-suited for wind/solar applications, street lighting or surveillance systems. Technical data:
- designed for 24V DC-systems
- max. 16A wind energy (1000W)
- max. 12A solar energy (300W)
- 2 x DC output: max. 10A total, 3 different modes
Reliability: Intellegent, module based design, simple mechanics, various functions. Thanks to high-quality components and a strict production process the regulator is able to last very long even under bad circumstances. Steplessly PWM regulated:
Voltage and current limitating charging mode: when the battery's max. voltage is reached the controller switches to voltage limitating mode. If the voltage, produced by the wind turbine, exceeds the max. voltage the regulator slows down the turbine. Each DC output with various control modes
LCD Display:
The LCD display shows status information and system parameter in numbers and graphical form: battery voltage; wind generator voltage and output; solar module voltage and performance, charging current, output control modes,
time control, light controll option, day/night detection, charging level, under/overvoltage of the battery, etc.
Category name:
Solar charge controller
Charge controller type:
Hybrid controller
Charging current (A):
10A
Display:
fixed integrated LCD display
Input current solar:
300 W
Input current wind:
400 W
Manufacturer:
Phaesun
Output voltage:
24 V DC
Own consumption in idle mode:
20 mA
System voltage:
24V DC
Temperature range:
-20°C to +55°C
Weight:
1,9 Kg
Manufactuerer Information
Phaesun
Phaesun GmbH
Bruhlweg 9
87700 Memmingen
Germany
Mail: info@phaesun.com
Tel.: +49 8331 990420
