Kemo m100n car ultrasonic marten repellent

The Kemo m100n car ultrasonic marten repellent produces aggressive ultrasonic sounds inaudible to humans, which are perceived by martens as extremely annoying and are therefore avoided if possible. Mounting in the motor vehicle engine compartment. Ultrasonic marten repellent for use in motor vehicles, houses and attics. Generates enormously loud, pulsating ultrasonic sounds with a special dome loudspeaker.

Technical data

• Powerful hemispherical dome loudspeaker, 2-fold effective - ultrasound + pulsating light
• Operating voltage: 11-15 v/dc (car battery)
• Soft-start, so that the on-board computer is not disturbed
• Average power consumption: <2mA
• Ultrasonic frequency: approx. 23 kHz
• Beam angle: approx. 140
• Sound pressure: max. ca. 110 dB ±20%
• Sound: loud pulsating
• Loudspeaker: ceramic piezo ultrasonic loudspeaker with aluminum dome diaphragm
• Optical deterrent: pulsating LED
• Temperature range: approx. -25°C to +80°C
• Electronics: waterproof encapsulated
• Fuse in fuse holder: F500mA
• Fused against voltage peaks in the vehicle electrical system up to 40v (<20 ms)
• Suitable for vehicles with CAN data bus

Installation instructions:

If the device is to be used against martens, then it is mounted in the engine compartment. It should be ensured that there is as much free space as possible in front of the loudspeaker opening of the device, so that the ultrasonic sounds can spread as far as possible in the engine compartment. Installation and commissioning may only be carried out by competent persons who also assume liability for any damage. Ultrasonic sounds propagate in a straight line like light, which means that the sounds may not be able to reach all corners. If the engine compartment is very fissured, then it may be necessary to mount several devices. You should try to orient the speaker opening so that, if possible, the cables and hoses most vulnerable to martens are directly illuminated by the marten repellent. The device must be mounted in such a way that no water or dirt can enter the housing. After applying the operating voltage of 11-15 v/dc, the built-in light-emitting diode on the device flashes. If this indicator light does not flash slowly, then either no voltage is applied or you have incorrectly polarized the voltage. Please take into account that ultrasonic sounds are only a very strong nuisance for animals.

Scope of delivery:

1x Kemo m100n kfz ultrasonic marten scare
