Goal Zero External 30a mppt-x for Yeti Power Station
Goal Zero's external 30A mppt kit (mpn 98085) ensures that generated energy can be quickly and safely stored in the Goal Zero Yeti expansion battery. The kit includes a Victron SmartSolar mppt 100/30 charge controller, a Goal Zero HPP extension cable to connect Goal Zero solar panels, and a Goal Zero EC8 extension cable so you can connect the Yeti Tank.
Victron SmartSolar mppt 100/30
The Victron mppt 100/30 charge controller is equipped with the mppt (maximum power point tracker) system. Especially in overcast conditions, when light intensity is constantly changing, the super-fast mppt algorithm improves energy output. The mppt technology ensures that the charge controller automatically adjusts to the changing voltage, transferring energy from the solar panel to the battery in a very effective way. By using a charge controller with mppt system, you use your solar panels up to 30% more effectively.
In addition, the Victron SmartSolar mppt 100/30 has an integrated Bluetooth module. A Bluetooth-enabled smartphone can display a variety of data live. The wireless solution to set up, monitor and update the controller using Apple and Android smartphones, tablets or other devices.
Technical data Victron mppt 100/30
- System voltage: 12V/24V
- max. charging current: 30A
- max. PV open circuit voltage: 100V
- max. PV power 12v: 440W
- max. PV power 24v: 880W
- integrated protection against battery polarity reversal
- high maximum efficiency of 98
- multi-stage and adaptive charging algorithm
- Day/night time control and light dimming option
- Protection class ip: ip43 (electronic components), ip22 (connection area)
Scope of delivery:
1x Victron SmartSolar mppt 100/30 charge controller
1x Goal Zero HPP extension cable
1x Goal Zero EC8 extension cable
